| Rim diameter | 14" - 42" |
| Rim diameter (with extensions clamp) |
14" - 52" |
| Max.wheel weight | 1600 kg |
|
Max.wheel width |
1050 mm |
| Max.tyre diameter | 2300 mm |
| Hydraulic pump motor | 2.2kW 380V - 3P - 50Hz (220V Optional) |
| Gearbox motor | 2.2kW 380V - 3P - 50Hz (220V Optional) |
| Machine weight approx | 758 kg |
| Noise level |
≤70dB |
| Operation control voltage | 24V |
| Temperature | 0oC ~ 40oC |
|
Overall dimensions approx |
2500 x 2000 mm |
|
Bead breaker force |
3300 kg |
| Power | 220/400V 50/60Hz 1P/3P Optional |
