AUTOMATIC TYRE CHANGER
T624
Features

* The customer can optional equip the plastic tool head according to the
   requirement.
The universal switch is 40A with a pure silver touching point, it can bear great
   load with a long using life.
* According to the customer's demand for the low profile tyre, the optional
   helper will ensure the working process more secure and reliable.
The protective sheath of the bead breaker is optional.
* You can optional equip the MJ-B motorcycle adaptor, convenient dismantling,
   stable and reliable to use. It will not harm the rim and can be use positive
   and negative. The adaptor will increase the clamping range.
* The claw, demounting head and bead breaking shoe are optional equipped
   with the protective cover. This can prevent the rim from being damaged for
   the operation incorrectly.
* The protective sheath of the bead breaker is optional.

Technical Specification
Rim Clamping from Outside
11″ -  20″
Rim Clamping from Inside
12″ -  24″
Maximum Wheel Diameter
950 mm
Wheel Width
 3″ -  12″
Operating Pressure
8 - 10 bar
Motor power
0.75 / 1.1 kW
Noise Level
<75dB
Net Weight
200 KG
Gross Weight
243 KG
Packing dimension
980×760×1010 mm
Volume
0.75m3
Quantity in 20” Container
34
Quantity in 40” Container
72
