AUTOMATIC TYRE CHANGER
T624IT
Features
* The customer can optional equip the plastic tool head according to the
   requirement.

* The universal switch is 40A with a pure silver touching point, it can bear great
   load with a long using life.
* According to the customer's demand for the low profile tyre, the optional helper
   will ensure the working process more secure and reliable.

* The protective sheath of the bead breaker is optional.
* You can optional equip the MJ-B motorcycle adaptor, convenient dismantling,
   stable and reliable to use. It will not harm the rim and can be use positive and
   negative. The adaptor will increase the clamping range.
* The claw, demounting head and bead breaking shoe are optional equipped with
   the protective cover. This can prevent the rim from being damaged for the
   operation incorrectly.
* The protective sheath of the bead breaker is optional.
Technical Specification
Rim Clamping from Outside
11″ -  20″
Rim Clamping from Inside
12″ -  24″
Maximum Wheel Diameter
950 mm
Wheel Width
 3″ -  12″
Operating Pressure
8 - 10 bar
Motor power
0.75 / 1.1 kW
Noise Level
<75dB
Net Weight
235 KG
Gross Weight
256 KG
Packing dimension
980×760×1010 mm
Volume
0.75m3
Quantity in 20” Container
34
Quantity in 40” Container
72
