Features
* Wheel balancer with self-owned intellectual property.
* This machine has the balance modes including of static and kinds of ALU
mode.
* With the car/truck conversion function key to guarantee the precision to be 50g
when handing truck tyre and 10g when handing car tyre.
* Equipped with inch to millimeter and gram to ounce conversion function.
* Standard 42mm thread shaft can be widely used as the universal accessory for
the domestic and overseas standard wheel balancer, flange disk and thread
shaft all undertaken supersonic quench and finish milling, strong durable and
beautiful.
* The display window and the weights cover is independent and difficult to damage
the screen when operation, the button board will be using more permanent.
* The customer can setup the minimum weight to display according to their
requirement.
Technical Specification
Rim Diameter
|
10″ - 24″
|
Max. Wheel Weight
|
200 KG
|
Max. Wheel Diameter
|
1200 mm
|
Rim Width
|
1.5″ - 20″
|
Rotating Speed
|
100/200 rpm
|
Working Pressure
|
5-8 bar
|
Motor Power
|
0.55 kW
|
Rated Power
|
585 W
|
Net Weight
|
238 KG
|
Gross Weight
|
304 KG
|
Packing Dimension
|
1300×990×1130 mm
|
Volume
|
1.45m3
|
Quantity in 20” Container
|
18
|
Quantity in 40” Container
|
42
|
