Features
* Hidden structure of lengthened broad pallet, make lift run smoothly and
synchronously, convenient for maintenance of vehicle underneath
* Driven by dual hydraulic cylinders, make it ascent and descent smoothly
* Imported hydraulic, pneumatic and electric components, with stable and
reliable equipment
* The ramp also can lengthen the runway, user for raising many kinds of cars
Technical Specification
Lifting Capacity
|
3.5 Ton
|
Lift height
|
280 - 2000 mm
|
Min. height
|
280 mm
|
Platform length
|
1420 mm
|
Platform width
|
560 mm
|
Gas source
|
6-8 kg/m3
|
Electric power
|
220V / 380V
|
Motor power
|
2.2KW
|
Net weight
|
860 kgs
|
Gross weight
|
910 kgs
|
